Application Scope
Rocket PCB's
PCB prototyping can be applied to different fields.Rocket PCB is rich in industrial experience and is sensitive about customers' needs. We can provide comprehensive and one-stop solutions based on customers' actual situations.
Company Advantages1. Different water purification technique has adopted by Rocket PCB pcb prototyping , such as physical and chemical filtration. These two purification techniques can greatly enhance the purifying effect.
2. The product only has superior quality but also has stable performance that customers can count on.
3. The product is known for durability and has a longer functional life.
4. The product is fully applicable in the most practical parts of our life.
Anylayer/ ELIC (Every layer interconnection)
In order to adapt to the development of CSP and inverted chip packaging (FC), it is necessary to use high density PCB with internal via hole (IVH) structure. In order to break through the limitation of traditional HDI high density interconnection laminates, it is necessary to import higher-order any layer interconnection technology so that any layer can be arbitrarily connected to another layer to form internal conduction.
The interconnection structure of via hole (IVH) is designed to be used in higher-level HDI products to achieve the purpose of light, thin, short and small.
![customized any-layer pcb free sample fabrication for sale 6]()
Advantages
Improving high Density Wiring of Products
Reduce the weight of PCB substrate: about 60%
Reduce the size of manufactured handsets: about 30%
......
ROCKET PCB Any Layer PCB （ELIC）process flow
![customized any-layer pcb free sample fabrication for sale 8]()
Anylayer PCB DFM suggestion for layout
![customized any-layer pcb free sample fabrication for sale 9]()
![customized any-layer pcb free sample fabrication for sale 10]()
Product FEATURES
◪ Any Layer PCBs with laser vias and filled plating on each layer
◪ 0.4mm thin spacing CSP supported by Any layer interconnection
◪ Mass-production of 10-layer M-VIA Ⅲ (Any Layer PCB) for mobile devices
ROCKET PCB STRENGTH
SPECIALIZED MANUFACTURING
Conductive materials and core-to-core bonding
Embedded components
RF connector attachment
Laser direct imaging (LDI)
Laser etching
Laser forming
Multi-level cavity construction
Plated cavities and edges
Composite/hybrid Structures
N+N dual press-fit
Dual-drill
Bonding on metal core
Bulid-up HDI
Long-short and staged gold finger
A wide range of professional manufacturing solutions, can be used for thermal energy (CTE) structural coefficients, thermal challenge design and application, extreme and unique HDI structures, and RF control
A wide range of professional manufacturing solutions, can be used for thermal energy (CTE) structural coefficients, thermal challenge design and application, extreme and unique HDI structures, and RF control
A wide range of professional manufacturing solutions, can be used for thermal energy (CTE) structural coefficients, thermal challenge design and application, extreme and unique HDI structures, and RF contro
CAPABILITIES
3mil line and space
4mil laser defined vias
6mil chip-on-board
6mil mechanically drilled vias
Conductive and non-conductive via fill
Dual backdrilling
Sequential lamination
Mixed dielectric
Heatsink Bonding
Heavy copper/thermal vias
Blind/buried vias
Stacked and staggerd microvias
EXTENSIVE ANALYTICAL TESTING![]()
Design Rules Check(DRC)
Electrical Testing
Automated Optical Inspection(AOI)
X-Ray
Plating thickness testing
Metalized vias inspection
Thermal shock testing
Surface peelability testing
Impedance control testing
100% visual inspection
Solderability testing
Ionic cleanliness testing
Metallographic microscopic analysis
High voltage testing
Insulating resistance testing
FEATURES
PTFE
High speed/low loss
High temperature
Low CTE
Lead-free, HASL, ENIG, EPENIG, Immersion Silver, Tin, Gold finger
Combination surface finished
Copper-filled microvias
Product application
![customized any-layer pcb free sample fabrication for sale 16]()
Consumer electronics
![customized any-layer pcb free sample fabrication for sale 17]()
Automotive electronics
![customized any-layer pcb free sample fabrication for sale 18]()
Communications
![customized any-layer pcb free sample fabrication for sale 19]()
Energy
![customized any-layer pcb free sample fabrication for sale 20]()
Industrial & Instrumentation
![customized any-layer pcb free sample fabrication for sale 21]()
IOT/Smart Home
![customized any-layer pcb free sample fabrication for sale 22]()
Medical electronics
![customized any-layer pcb free sample fabrication for sale 23]()
Security Industry
Rocket PCB has received more and more compliments for its finest quality
any-layer pcb .
2. We have an exceptional team of designers. They work consistently to provide innovative and functional design and achieve the highest levels of product quality.
3. We take environmental and energy-related problems into our consideration as early as the planning and development phases. In terms of water consumption, waste management, and energy conservation, we are working hard to achieve progress. We work with ISO-certified suppliers who have the right working conditions, working times, and who conduct their work without undue risk or pressure. Rocket PCB series is manufactured in strict accordance with international standards.
